THE ELITE FISHING SYSTEM ™
The new Elite Fishing System (FS) gives you access to the full line-up of Lowrance fish finding tools – including ActiveTarget™ Live Sonar, Active Imaging™, Fish Reveal and preloaded C-MAP® Contour™+ charts – to help you make the most of your time on the water.
NETWORKING
For the first time ever, Ethernet networking comes to the Lowrance Elite family, share sonar, charts, waypoints and other user data between multiple displays. Support and control of NMEA2000® devices, build the complete Elite Fishing System for freshwater or saltwater.
Perfect for pinpointing fish-holding areas like rockpiles, standing timber, weedbeds, ditches and drop-offs, Active Imaging™ sonar delivers superior clarity and the highest resolution images of fish and structure at a longer range than any other structure-imaging technology.
*Transducers sold separately.
ACTIVETARGET
Watch high-resolution images of fish movements – tracking them as they swim in and around cover with ActiveTarget Live Sonar. When you see how fish are located near structure and watch them respond to your lure, you will know if your current technique is working, or if it’s time to make an adjustment – information that is harder to get from traditional sonar or structure imaging.
Track fish and your presentation with high-resolution views in front or below your boat, or use the Scout mode to see an ultra-wide, overhead view of structure and fish activity in front of your boat, perfect for finding bait balls and big schools of fish. Game on.
*Transducers sold seperately.
HIGH RESOLUTION MULTITOUCH SCREEN
The best screen yet in our Elite Series, multi-touch with a flat glass screen and anti reflective coating gives great visibility in all light. A single user programmable key allows for quick selection of those vital and most used interactions.
Technical Specifications
Specifications | Elite-7 FS | Elite-9 FS | |
Screen Size | 7″ | 9″ | |
Power Consumption max | 0.9A @ 13VDC with backlight on full | ||
Power Consumption typical | 0.9A @ 13VDC with backlight on full | ||
Power Consumption min | 0.9A @ 13VDC with backlight on full | ||
SD Card Storage | 1 micro SD card up to 32GB | ||
Ethernet Ports | 1 virtual ethernet port + Navico Ethernet Port | ||
Update rate | 10 Hz | ||
GPS | 10 Hz Internal high-sensitivity WAAS + EGNOS + MSAS | ||
Shock Vibration | 100,000 cycles of 20 G | ||
Compass Safe | 12″ (300mm) | ||
Screen Brightness | 1200 nits | ||
Supply Voltage | 12v DC (10.8-17VDC) | ||
GPS Receiver Channels | 16 | ||
NMEA 2000 Connectivity | 1x Micro-C | ||
Warranty Period | 2 years + 3 additional years of upgrade options. Totaling 5 years | ||
Weight (Display Only) | 0.91 kg (2.0 lbs.) | 1.32 kg (2.9 lbs.) | |
Position Accuracy | 20m RMS | ||
Waypoints, Routes, Tracks | 3000 Waypoints100 Routes100 Trails with up to 10,000 points per trail | ||
Time to First Fix | 30s | ||
Recommended Fuse Rating | 3A | ||
Storage Temperature Range | 4°F to 140°F (-20°C to 60°C ) | ||
Operating Temperature Range | 5°F to 131°F (-15°C to 55°C ) | ||
Humidity | 60°C, 95% relative humidity (RH) for 18 hours | ||
Viewing Angles | 80° top/bottom, 85° left/right | ||
Display Resolution | 800×480 | ||
AIS | AIS Chart overlay. Target vessel details. | ||
Charts supported | C-MAP (MAX N, MAX N+)C-MAP GenesisC-MAP Precision Contour HD (AMER ONLY)Navionics (Gold, NAV+ Platinum+)Insight (Pro and HD)Lowrance Regional Mapping Partners | ||
Cartography included | C-MAP US Costal / ROW Basemap (US Costal/ROW models)Navionics basemap (AMER, AUS/NZ and US Costal/ROW models) | ||
Correction | DGPS, WAAS | ||
Mounting Type | Gimbal Bracket or Dash Flush Mount | ||
Bluetooth | Integrated | ||
Sonar Compatibility | Integrated: CHIRPBroadbandActive Imaging DownScanActive Imaging SideScanCompatible with:StructureScan | ||
Item Connectivity WiFi | Internal 802.11b/g/n | ||
Waterproofrating | IPX7 with card door closed | ||
Languages | Asian Language Pack: English (US), English (UK), Japanese/日本語, Korean/한국어, Thai/ภาษาไทย, Chinese – (simplified) China/简体中文, Chinese – (traditional) Taiwan/繁體中文 | ||
Autopilot | MotorGuide Xi5/Xi3 Trolling Motor *requires Motorguide PinPoint Gateway | ||
Radar compatibility | Lowrance HALO Radar | ||
Weather | None | ||
Internal Storage | None (Use Micro SD Card Slot) | ||
PC Connectivity | None | ||
Video | None | ||
Multimedia | None | ||
Digital Switching | None | ||
Backlight Color | Pure White LED | ||
Interface | TouchscreenZoom +/-MOB = (+/- combined)PagesWaypointLight/Power |
